SPACE CAMERAS

iSIM optical payloads

Our products

iSIM (integrated Standard Imager for Microsatellites) is a new generation of High and Very High-Resolution optical imagers for Earth Observation satellites with video capability, developed by SATLANTIS. The iSIM instrument operates simultaneosly in the visible, near infrared and short-wave infrared spectral ranges, supporting innovative applications.

For further technical specifications contact us

Key features of iSIM Technology

Image Quality

Smart Image Box

Multispectral / Panchromatic

Customer Configuration

Light Weight

Agility & Backscanning

Large Swath

Heritage in Space

Tir Thermal

iSIM Optical Payloads Overviews

iSIM (integrated Standard Imager for Microsatellites) is a new generation of High and Very High-Resolution optical imagers for Earth Observation satellites, with video capability.

The iSIM instrument operates in the visible, near infrared and short-wave infrared spectral ranges, supporting innovative applications to address challenges in sectors such as detection and quantification of methane emissions (Oil&Gas), Defence and Security, monitorisation of infrastructures, precision agriculture.

Ultra-high resolution

Ultra-High Resolution is a technique used to retrieve a high spatial resolution image from a series of low spatial resolution images, without loss of information.

SATLANTIS has developed its own Ultra-High-Resolution algorithm that can improve the resolution by a factor of up to 2.5. Additionally, onboard processing of ultra-resolved images allows significant reductions in the amount of data to download to the Ground stations.

SATLANTIS has expanded its UHR algorithm to create a new concept, the iSIM Smart Imaging, that enables a customization of three key parameters of the algorithm based on customer needs or mission requirements. These parameters allow a tuning of spatial resolution, contrast and signal due to their interplay within the algorithm’s code.

Before image alt After image alt

iSIM 90 - Main Features

MASS: < 4 kg - targeted for 12/16U CubeSats

SWATH (at 500 km)

PAN & VNIR: 13 - 23,5 km
SWIR: 8,2 km

IMAGING GSD (at 500 km)

PAN & VNIR: 2 m
SWIR: 5 m

HERITAGE: validated in Space in Q4 2021

iSIM 170 - Main Features

MASS: <15 kg targeted for Microsatellites

SWATH (at 500 km)

PAN & VNIR: 7,5 - 13,5 km
SWIR: 4,2 km

IMAGING GSD (at 500 km)

PAN & VNIR: 1 m
SWIR: 2,5 m

MULTISPECTRAL BANDS

HERITAGE: validated in Space in Q2 2020
